TI-NF725
5.0MP Panoramic IP Camera
● 5.0MP Panoramic IP Camera
● 1.56mm(5MP)Lens, Horizontal 180°Vertical 360°
● 2592×1920 10FPS ,2048×1536 20FPS ,1920*1080@25fps
● 2/4/8/9 Split Screen
● Support P2P remote view and Fisheye correction by PC software,Low stream
● IR LED: 3pcs IR LED，IR Up to 10M
● Metal Casing, TF card: Max 32G ,IR distance:10M，Support audio
● POE Optional(Ethernal)
|
|
MODEL
|
TI-NF725
|
|
Main Processor
|
TI
Davinci DM368
|
|
Sensor
|
5
Megapixel CMOS sensor
|
|
Max. Res./Max Frame Rate
|
2592*1920@10fps(single stream)
|
|
1920*1080@25fps(dual stream)
|
|
2048*1536@18fps(dual stream)
|
|
CAMERA
|
|
Day/Night
|
Yes
|
|
Lens
|
1.56mm
Fixed Lens
|
|
IR Cut
|
Support
|
|
IR LED
|
Yes
|
|
IRIS
|
Fixed
Aperture F1.2
|
|
Viewing
Angle
|
360°
|
|
VIDEO
|
|
Compression
|
H.264
|
|
Code Stream
|
32-4096kbps
|
|
Bit Rate Type
|
CBR
& VBR
|
|
SNR
|
Above
50DB
|
|
Image Enhancement
|
Automatic
White Balance, Backlight Compensation,Luminance, Contrast, Color Adjustment
|
|
Video Cover
|
4
Region can be set up
|
|
Superposition of Words
|
User
Defined
|
|
NETWORK
|
|
Flip Config
|
Up/Down,
Left-right-flip
|
|
Audio Compression
|
G.711/G.726
|
|
Alarm Procession
|
The
central control monitor, Got to PTZ preset , Send E-mail, Log Record, SD
Card storage, etc.
|
|
Protocol & Service
|
TCP,UDP,IP,HTTP,SMTP,DHCP,DNS,DDNS,ARP,ICMP,SMTP,POP3,NTP,RTP,
RTCP, Pelco-D
|
|
Ethernet Port
|
Ethernet
(10/100 Base-T),RJ-45 connector applications.
|
|
Security
|
IP
Address Filter,User Password Protection, User Access Log
|
|
Software
|
|
WEB Browser
|
Microsoft
Internet Explorer 6.0 or above, google, firefox , etc
|
|
Software Management
|
Multi- Multi-channel Network Surveillance System
ONVIF Compatibility channel Network Surveillance System ONVIF Compatibility
|
|
Motion detection and IO alarm center remind and
screen pop-up linkage, unified client remote monitoring software (UC2) and
VM3000 platform etc. system, phone monitoring (Iphone, Android ), through
service “through clouds” P2P and provide complete development kit SDK
|
|
GENERAL
|
|
Accessories
|
Power
adapter, Network Cable, Stand, User Manual, Disk, Screw Bag
|
|
Power Consumption
|
DC
12V/1A
|
|
Operation Temperature
|
10°C——60°C
|
|
Operation Humidity
|
10%-80%
|
|
Remote Access
|
DDNS,
software, P2P
|
|
|
|
|
|
