Thermal Imagery Module：
Ø Thermal Image Pixel 256*192
Ø Sensor Size 12μm
Ø Non-contact Temp Measurement，Accuracy±0.3℃
Ø Temp Range：-15℃~550℃
Ø Max Temp，Min Temp，Average Temp，Temp data OSD Overlying display
Ø Full-screen temperature measurement ，Auto tacking the Max temp and Min Temp of full screen
Ø Support Manual Temp range selection.
Ø Support white heat, black heat, fusion, rainbow, autumn, noon, iron red, amber and other pseudo-color adjustable
Visible Light module：
Ø 1/2.8” 2.0M CMOS Image sensor；
Ø 0.005Lux@F1.2 color，0.001Lux@F1.2 B/W；
Ø Max resolution up to 1920x1080@30fps；
General Function：
Ø The embedded depth learning algorithm supports the function of face capture, which can detect and capture 20-30 faces simultaneously；
Ø Support for face tracking and scoring, multi-frame recognition, automatic filtering and output of the optimal face, and reduce repeated capture；
Ø Built in 50000 Face database；
Ø Support H.265+ /H.265 / H.264 +MJPEG dual coding，Three-code stream
Ø Support ONVIF、GB/T28181 and other network protocols, networking easier；
Ø A single IP scheme, rich network expansion ability, easy access to various video surveillance platforms
Ø Open system, can provide Linux、Windows SDK development package and CGI protocol, rapid secondary development。
|
